* Wide measuring range. It can measure the hardness of all metallic materials. Direct display of hardness scales HRB, HRC, HV, HB, HS, HL and three types of strength values immediately.
* Large 3 inch screen LCD, showing all functions and parameters. With EL background light.
* Seven impact devices are available for special application. Automatically identify the type of impact devices, and with the user calibration function.
* Test at any angle, even upside down.
* Large memory could store 500 groups (Relative to average times 32-1) information including single measured value, mean value, impact direction, impact times, material and hardness scale etc.
* Battery information showing the rest capacity of the battery and the charge status.
* Original imported high speed thermal printer support the immediate printing function. It can save data permanently.
* NI-MH rechargeable battery as the power source. Charge circuit integrated inside the instrument. Continuous working period of no less than 150 hours (EL off and no printing).
* Auto power off to save energy.
* Excellent after-sale service system for high quality products two years’ guarantee and all life maintenance. Easy to buy and comfortable to use.
Name | Specification |
Measuring range | (170-960)HLD |
Measuring direction | 0°-360° |
Hardness Scale | HL、HB、HRB、HRC、HRA、HV、HS |
Display | segment LCD |
Data memory | 500 groups max.(relative to impact times 32-1) |
Printing paper | width is (57.5±0.5)mm, diameter is 30mm. |
Battery pack | 6V NI-MH |
Battery charger | 9V/500mA |
Continuous working period | about 150 hours（With backlight off, no printing） |
Communication interface | USB2.0 |
Outline dimensions | 212mm×80mm×32mm |
1,NDT Prodcuts factory with 30 years' experience
2, professional technical team, free training
3, 24 hours' service, reliable partner
Q: How long will you give customer the reply? A: We will contact you soon. The latest will not exceed 10 hours. Q: How about the quality of the products? A: We have the certificates of ISO and CE. We can send our certificates to you for your reference. Q: What is the price of the product? A: As we all believe the quality is the most important. We will provide the best quality machines with best price. Q: How about delivery time? A: Most of our products are in stock, after testing to your delivery, delivery time is about 5-7 days. Q: Can we visit your factory? A: Of course, please feel free to visit our factory. Q: How long is the warranty? A: 12 months. Warranty period free maintenance. | ||||||||
